Hasimoto HWC-30-5 Output Transformer - Push Pull (with SG tap)

Main Specifications
Output: 30W at 50Hz
Inpedance Primary / Secondary: 5kΩ / 4, 8, 16Ω
Frequency Response ( ± 1dB ): 10 ~ 50kHz
Insertion Loss: 0.2dB
Maximum DC Current Balance / Unbalance: 220 mA / 5.0 mA
Primary Inductance Balance / Unbalance: 100H / 80H

Suitable Tubes
EL-34, 2A3, 6A3, 45, 6L6GC, 6B4G, VT52
